Description
Includes:
- Complete Seawater Strainer #JPR-ST4020
QTY: 1
PRODUCT DESCRIPTION
| SPECIFICATION | JPR-ST4020 |
| PORT SIZE: | 1 1/2″ (PIPE) – NPT |
| TOP CASTING | Bronze |
| BOTTOM CASTING | Bronze |
| BASKET | Stainless |
| BASKET REPLACEMENT P/N | FIL000302 (2mm) |
| ANODE REPLACEMENT P/N | ZEN000101 |
| SEAL | O-Ring |
| SIZE (A X B X C, mm) | 210 x 334 x 235 |
| CYLINDER (Dia X H, mm) | 180 x 190 |
| WEIGHT (Approx.) | 10.0 kgs |
PLEASE NOTE A,B,C SIZE STANDS FOR:
(A) Top Width / Dia = 210mm
(B) Height = 334mm
(C) Bottom Width / Dia = 235mm
PERFORMANCE TABLE – FLOW CHART
| Bar | 500rpm | 1000rpm | 1800rpm | 2000rpm |
| 0 | 66 L/Min | 138 L/Min | 268 L/Min | 295 L/Min |
| 1 | 57 L/Min | 122 L/Min | 250 L/Min | 283 L/Min |
| 2 | 44 L/Min | 103 L/Min | 232 L/Min | 250 L/Min |
| 3 | 21 L/Min | 77 L/Min | 175 L/Min | 203 L/Min |
| Max | 3.4 bar | 4.2 bar | — | — |
FEATURES
- Robust Bronze Casting
- Robust Stainless with Chrome Plated Filter Baskets
- Easy Installation
- Easy Maintenance and Cleaning
- Protects Your Pumps and Engines
- Transparent and Strong Cylinder
- O-Rings Provide Better Sealing under High Pressure Applications
- Zinc Bar
- Wingnut
- Center Rods
- Air Cap
