Description
Includes:
- Complete Sea Water Strainer #JPR-ST2020 (NPT Ports)
QTY:1
PRODUCT DESCRIPTION
| SPECIFICATION | JPR-ST2020 |
| INLET / OUTLET PORT SIZE: | 1″ (PIPE) – NPT |
| TOP CASTING | Bronze |
| BOTTOM CASTING | Bronze |
| BASKET | Stainless |
| BASKET FILTER REPLACEMENT P/N | FIL0008 (3mm) |
| ANODE REPLACEMENT P/N | ZEN000101 |
| SEAL | O-Ring |
| SIZE (A X B X C, mm) | 150 x 220 x 180 |
| CYLINDER (Dia X H, mm) | 130 x 100 |
| WEIGHT (Approx.) | 13.5 lbs / 6.15 kgs |
PLEASE NOTE A,B,C SIZE STANDS FOR:
(A) Top Width / Dia = 150mm
(B) Height = 220mm
(C) Bottom Width / Dia = 180mm
PERFORMANCE TABLE – FLOW RATE
| Bar | 500rpm | 1000rpm | 1800rpm | 2000rpm |
| 0 | 27 L/Min | 58 L/Min | 106 L/Min | 122 L/Min |
| 1 | 25 L/Min | 53 L/Min | 100 L/Min | 116 L/Min |
| 2 | 20 L/Min | 44 L/Min | 86 L/Min | 100 L/Min |
| 3 | — | 24 L/Min | 63 L/Min | 77 L/Min |
| Max | — | 3.6 bar | 4.4 bar | — |
FEATURES
- Robust Bronze Casting
- Robust Stainless with Chrome Plated Filter Baskets
- Easy Installation
- Easy Maintenance and Cleaning
- Protects Your Pumps and Engines
- Transparent and Strong Cylinder
- O-Rings Provide Better Sealing under High-Pressure Applications
- Zinc Bar
- Wingnut
- Center Rods
- Air Cap
