Description
DrägerTube Charcoal Type BIA
PN: 6733011
With the Dräger activated carbon tubes, the hazardous substances contained in the air are first collected by adsorption or chemisorption. The sample is then qualitatively and quantitatively tested in the laboratory using instrumental analysis such as gas chromatography (GC), high-performance liquid chromatography (HPLC), UV-VIS photometry or IR spectroscopy. Measurements: 10
| Application Range | |
| Adsorbate | organic compounds which adsorb on activated charcoal |
| Sorption agent | coconut shell charcoal |
| Adsorption layer | 300 mg |
| Backup layer | 600 mg |
| Tube Length | 125 mm |
| Outside diameter | 7 mm |
| Inside diameter | 5 mm |
| Advice for sample-taking |
| This construction is developed, for a high adsorption capacity of the sampling layer. This tube is typically sufficient for sampling in the range of limit value measurement. If higher concentrations of harmful substances are expected, the sampling tube must be inserted with the air flow opposite to the flow indicating arrow ( long layer in front; note in the sampling record). After sampling the tube should be sealed with the polyethylene supplied caps. |
