Description
Dräger-Tube Carbon Monoxide 5/c (10 Tests per Box)
PN: CH25601
Dräger-Tubes™ are used together with a Dräger tube pump for measurements of gases, vapors and aerosols, usually in air, and are one of the classic methods of gas analysis. This Dräger-Tube is used for the detection of carbon monixide and has the following standard measuring ranges: 100-700 ppm 5-150 ppm Measurements: 10
| Application Range | |
| Standard Measuring Range | 100 to 700 / 5 to 150 ppm |
| Number of Strokes n | 1 / 5 |
| Time for Measurement | approx. 50 s / approx. 150 s |
| Standard Deviation | ± 10 to 15% |
| Color Change | white to brownish – green |
| Ambient Operating Conditions | |
| Temperature | 0 to 50 °C |
| Absolute Humidity | max. 50 mg H2O/L |
| Cross Sensitivity |
| The following have no influence on the display of 10 ppm CO(respectively): 200 ppm n-octane, with carbon attachment tube (CH 24101) 10000 ppm 30 ppm benzene 100 ppm hydrogen sulphide 50 ppm sulfur dioxide 15 ppm nitrogen dioxide 40 ppm butadiene 10 ppm CO + 100 ppm benzene : display approx. 20 ppm 10 ppm CO + 40 ppm chloroform: display approx. 60 ppm 10 (60) ppm acetylene: display 8 (20) ppm |
