Agm224 Grain and Seed Cleaning Machine by Clipper

Description

Note: Domestic/Export crating must be selected with the items above.

Product Literature

The Clipper AGM224 cleaner is a mid-range cleaner that will provides excellent results and fits the market for those in need of a cleaner larger than the Office Clipper and smaller than the Eclipse 324 cleaner. This unit is ideal for small production, in lab, or on-farm applications. The AGM224 is a durable cleaner and features a steel frame, galvanized steel shoe, scotch-ply hangers, heavy-duty eccentric (shoe) drive, ball tray cleaning system and plain inlet hopper. Designed with two (2) 24½” x 22¼” screens. The top screen handles scalping while the bottom screen offers thorough cleaning and grading. An adjustable air separation efficiently completes the cleaning process. With over 175 different screen sizes (perforated metal and wire mesh) available the AGM224 is an extremely versatile machine.
Actual wt: 575 lbs.
Actual dims: 54″L x 41″W x 67″H.
Ship wt: 895 lbs.
Ship dims: 56″L x 45″W x 70″H.

All seed cleaner screen sizes (perforations and wire mesh) may be found on page 86 in the catalog or clicking on this link: Hand Testing Screens.

*Capacity may vary depending on seed condition, moisture content, seed varieties, types and volumes of contaminants to be separated and the percentage of foreign material acceptable in final product. Capacities shown above are for the split-flow arrangement.
